 当前位置:首页 > 产品中心 > 贵金属回收装置 > F-1一体型提银机
 F-1一体型提银机
  产品型号:F-1  参考价格: 面议   产地:中国  产品编号:LB1147



创新点

◆ 国际技术专利自主技术专利结合先进全自动提银机 The most advanced full automatic silver extracting machine combine with the domestically and the internationally patent technology,utillizing full automatic treatment of waste solution by control with PC in the working process. ◆ 智能电源模块智能电解,确保提银纯度及提银深度 Making use of intelligent power module to adjust the electrolytic current to waste solution concentration to ensure the silver purity and the depth of waste solution treatment. ◆ 提出白银数量提示、提银自动报警、万年历功能 Viewing at any time the amount of silver extracted by activating the internal readtime monitor module of the machine;giving alarm for user to remove the silver when reaching acertain thickness on the cathode.


仪器介绍

F-1一体型提银机系一款结合美国和俄罗斯专利技术,并有自主技术专利的,经过中国市场近十年的磨砺,根据客户使用反馈信息,对产品不断改进更新而推出的用户使用界面友好型的提银机。产品一经推出市场,深受用户信赖与喜爱并远销东南亚地区及乌克兰和俄罗斯。 基于长期银回收经验研发、制造、改进的F-1一体型提银机,特别适合用于提取回收无损检测、菲林输出、光绘制版等行业的废定影液、彩扩行业漂定液及银电镀液中的银。这是一款实用的,高回报性的设备,可以根据所处理废液的成份不同而调节操作参数,使用简便安全,外观设计便捷轻巧是该型提银机的主要特点。所回收的银成块状,纯度高于98%,平均提银速度达110g/h.


技术参数

■ 处理废液中银的深度高于99.5%,提取白银纯度99.8%以上 The depth of waste solution treatment for silver is over 99.5% and the purity of silver extraction over 99.8% ■ 运行实现微机全自动化控制,无需专人看管,耗能低(功率小于40W),无二次污染 Full automatic control by PC and no tending by people necessary during operation,low energy consumption (power less than 40W)and free from secondary pollution. ■ 残留废液银含量可低于0.010克/升。 The Silver content in residual waste solution lower than 0.01g/L ■ 可以处理目前国内外电解法难以处理的彩扩漂定液、电镀废液等中的银 Able to treat the color enlargement blix with a high content of bleaching beyond treatment currently with the electrolytic process domestically and abroad. ■ 本设备不需要任何耗材和电解促进剂,运营维护方便,成本低。 Needing no consumable and electrolytic promoter,it is convenient for operation and maintenance and low in cost. ■ 全防腐设计,机件寿命长,取银方便 Complete anti-corrosion design ,long service life for machine parts,convenient to get silver.


应用领域

应用于印刷菲林输出行业、线路板菲林光绘制版行业、彩扩冲印行业,医疗X光、工业无损探伤、纺织印染印花菲林输出行业的含银定影液及漂定液以及电镀行业的含银废液的电解提银回收。 F-1 Compact Silver Extracting Machine can be applied to the folowing indutries: Printing film plate making,PCB film ploter,the color enlargement,midical X-ray,industrial flow detection,textile and dye printing, Silver plating,tail washings of silver ore,etc. F-1 Compact Silver Extracting Machine can recovery the silver from the waste fixer solution, the color enlargement blix with a high content of bleaching,the silver plating waste solution.

技术特点

产品高收益比率---物有所值/Good value for margin

提银机提取白银的收益是非常可观的,以一个普通规模的制版公司为例:每个月产生的定影废液约1000升,按每升含银量15克计算,可提取白银约15000克,每克按3.9元计算,价值为58,500.00元,是出售废液价值的4-5倍,其它行业可参考下表:

规模

中等规模光绘公司/菲林输出中心

普通医院X光科

普通彩扩店

月均废液量

1000L

300L

300 L

废液银含量

15/

10/

3/

可提取银

15,000

3,000

900

银价值

58,500.00

11,700.00

3,510.00

The benefits from extracting silver in the waste solution with the silver extracting machine is quite considerable .Taking an middle- scale film ploter company as an example:

Around 1000L  waste fixer solution can be generrated each month ,generrally speaking,it contains 15 g silver per liter waste solution. In other words,around 15,000g silver can be extracted from the waste fixer solution each month which worth RMB 58,500.00 when based on the silver price RMB 3.9 yuan per gram,which is 4~5times in contrast with direct selling the waste solution.Please refer to the following table for other trades:

scale

Middle-scale film ploter company

Ordinary hospital X ray

Ordinary color enlargement shop

Waste solution

each month

1000L

300L

300 L

Silver content of waste solution

15g/L

10g/L

3g/L

Silver available for extraction

15,000g

3,000g

900g
